FirePASS® FP-5000 to FP-20000 Oxygen Reduction Systems

FirePASS® FP-5000 to FP-20000 oxygen reduction fire prevention systems are engineered for continuous fire protection in very large enclosed spaces.

Designed for protected volumes from approximately 10,000 m³ to 100,000 m³ and beyond, these high-capacity systems continuously generate oxygen-reduced air to maintain the engineered oxygen concentration within the protected environment.

The FP-5000 to FP-20000 range is designed for large-scale applications where fire prevention, asset protection and operational continuity are critical.

Large-Scale Oxygen Reduction Fire Prevention

The FirePASS® FP-5000 to FP-20000 range is designed for facilities where large protected volumes require a powerful and reliable oxygen reduction system.

Instead of waiting for a fire to develop, FirePASS® continuously supplies oxygen-reduced air to maintain a controlled atmosphere in which the risk of ignition is significantly reduced.

This makes the FP-5000 to FP-20000 range particularly suitable for large, controlled environments where conventional fire suppression could result in operational disruption or secondary damage.

Applications for the FP-5000 to FP-20000

FirePASS® FP-5000 to FP-20000 systems are designed for large-scale fire prevention applications and can be engineered around the requirements of the protected facility.

Typical applications can include:

• Automated and high-bay warehouses
• Large data centers
• Industrial storage facilities
• Critical infrastructure
• Large archives and storage environments
• Other high-volume enclosed spaces

System capacity and configuration are determined according to factors such as protected volume, air leakage, required oxygen concentration and the specific fire protection requirements of the facility.

How the FirePASS® FP-5000 to FP-20000 Works

The FP-5000 to FP-20000 system generates oxygen-reduced air from normal ambient air and supplies it continuously to the protected environment.

Dedicated oxygen monitoring continuously measures conditions within the protected space, while the FirePASS® control system regulates operation to maintain the engineered oxygen concentration.

This provides 24/7 oxygen reduction fire prevention rather than relying solely on a suppression system that activates after a fire has been detected.

Key Features

• Designed for protected volumes from approximately 10,000 m³ to 100,000 m³ and beyond
• Continuous oxygen reduction fire prevention
• High-capacity oxygen-reduced air generation
• Continuous oxygen monitoring and system control
• Engineered for large enclosed environments
• No water or chemical extinguishing discharge during normal prevention operation
• Scalable system configuration for demanding applications
• Designed to protect critical assets, infrastructure and operations

Complete FirePASS® System Configuration

The FP-5000 to FP-20000 generator can be integrated with FirePASS® monitoring and control technology to create a complete oxygen reduction fire prevention system.

Depending on the application, the system can include FirePASS® control panels, continuous oxygen monitoring and ambient oxygen monitoring, providing continuous measurement, regulation and supervision of the protected environment.

Each installation is engineered according to the characteristics and fire protection requirements of the facility.
